Welcome to DeepLines Version 5.8.

DeepLines and its module Wind is an integrated software dedicated to the design of a large variety of offshore systems:

  • Moored floating platforms (FPSO, CALM buoy, Windturbine...),
  • Fixed structures (Jacket, monopile...),
  • Flexible or rigid risers,
  • Pipelines,
  • Floating hoses,
  • Umbilicals, fiber optical cables, power cables.
The software package combines a powerful beam finite elements engine with advanced modeling capabilities (contacts, diffraction/radiation, non-linear laws) and an intuitive user interface offering optimum productivity through multi-tasking. DeepLines allows performing both in-place analyses (fatigue, extreme, accidental) and installation scenarii and offers advanced post-processing features (structural code checks, rainflow couting, clash checks). This numerical tool is based on the program Flexan, initially developed for flexible risers and used from 1980 by Coflexip Stena Offshore (CSO). Ever since, DeepLinesTM field of application has been extended to perform conceptual, basic and detail design of different systems in the Oil & Gas industry : drilling risers, hybrid towers, bonded and unbonded flexible risers, offloading lines, fibre optical cables. In the 90ies, the DeepWater context requires the introduction of coupled simulations for the overall analysis of a Floating Production System. To do so, DeepLinesTM was closely coupled with DiodoreTM, the diffraction/radiation solution developed by PRINCIPIA, to take into account the interactions between any floating unit and its mooring lines or risers. External links with other diffraction/radiation softwares were also made possible. At last, to address the needs for an overall design tool raised by the development of offshore windturbines platforms, a new module DeepLines WIND was created in 2011. For that purpose, DeepLinesTM structural model was extended to handle wind turbine specificities, specifically for the modelling of blades and rotors rotation. Several BEM models are implemented in an external DLL to calculate the aerodynamic loads.

Check out what's new to learn about changes and enhancements brought in this version of DeepLines.

This help system provides information on the following items:

  • Getting started: This section provides an overview of DeepLines.

  • Version history: This section documents the changes made to the versions of DeepLines.

  • User interface: This section gives all details on how to use the user interface.

  • Model components: This section lists all model components available in the user interface to setup your model.

  • Theory: This section provides some theoretical background on the technical features used to model your system.

  • List of keywords: This section lists all the keywords which can be read by the FE engine from the LOG input files.
